Temperature and Pressure Relief Valves

This temperature and pressure relief valve has a bronze body and stainless steel spring, with a 4 3/4-inch long thermostat and 6 7/8-inch long shank. The valve body measures 1 1/2 x 6 7/8 inches and has a 3/4-inch FNPT inlet and outlet. The factory-set pressure is 150 psi and maximum temperature is 210 Degrees F with a 205,000 BtuH. The valve is auto-reseating and meets CSA 4.4 standards.

This temperature and pressure relief valve has a bronze body and stainless steel spring, with a 4 3/4-inch long thermostat and 6 7/8-inch long shank. The valve body measures 1 1/2 x 6 7/8 inches and has a 3/4-inch FNPT inlet and outlet. The factory-set pressure is 150 psi and maximum temperature is 210 Degrees F with a 205,000 BtuH. The valve is auto-reseating and meets CSA 4.4 standards.

This temperature and pressure relief valve has a maximum temperature of 210 Degrees F, 105,000 BtuH, and a factory-set pressure of 150 psi. Its MNPT inlet and FNPT outlet each measure 3/4 inches and it has a 1 7/8-inch long thermostat and 2 5/16-inch long shank. The body is bronze and measures 1 15/32 x 4 5/16 inches, and the valve is auto re-seating with a stainless steel spring. It meets CSA 4.4 standards.

This temperature and pressure relief valve has a maximum temperature of 210 Degrees F, 105,000 BtuH, and a factory-set pressure of 150 psi. Its MNPT inlet and FNPT outlet each measure 3/4 inches and it has a 1 7/8-inch long thermostat and 2 5/16-inch long shank. The body is bronze and measures 1 15/32 x 4 5/16 inches, and the valve is auto re-seating with a stainless steel spring. It meets CSA 4.4 standards.

This temperature and relief valve has a 150 psi factory-set pressure with a maximum temperature of 210 Degrees F and 750,000 BtuH. Its shank length is 5 7/8 inches, thermostat length is 4 3/4 inches, and its bronze body measures 1 3/4 x 5 7/8 inches. It has an FNPT-type inlet and outlet, with a 1-inch inlet and 3/4-inch outlet. It has a stainless steel spring and is auto-re-seating. This valve meets CSA 4.4 standards.

This temperature and relief valve has a 150 psi factory-set pressure with a maximum temperature of 210 Degrees F and 750,000 BtuH. Its shank length is 5 7/8 inches, thermostat length is 4 3/4 inches, and its bronze body measures 1 3/4 x 5 7/8 inches. It has an FNPT-type inlet and outlet, with a 1-inch inlet and 3/4-inch outlet. It has a stainless steel spring and is auto-re-seating. This valve meets CSA 4.4 standards.

This bronze, temperature and pressure relief valve is auto re-seating with a factory-set pressure of 150 psi, and a maximum temperature of 210 Degrees F with a 105,000 BtuH. The thermostat is 2 1/8 inches long, the shank length is 2 3/32 inches, and the body measures 1 15/32 x 4 5/16 inches. The MNPT inlet and FNPT outlet are each 3/4 inches and the valve comes with a stainless steel spring. It meets CSA 4.4 standards.

This bronze, temperature and pressure relief valve is auto re-seating with a factory-set pressure of 150 psi, and a maximum temperature of 210 Degrees F with a 105,000 BtuH. The thermostat is 2 1/8 inches long, the shank length is 2 3/32 inches, and the body measures 1 15/32 x 4 5/16 inches. The MNPT inlet and FNPT outlet are each 3/4 inches and the valve comes with a stainless steel spring. It meets CSA 4.4 standards.

This temperature and pressure relief valve has a factory-set pressure at 150 psi with a maximum temperature of 210 Degrees F and 185,000 BtuH. Its thermostat length is 1 5/32 inches, shank length is 5 7/32 inches, and bronze body measures 1 17/32 x 5 7/32 inches. Its MNPT inlet and FNPT outlet each measure 3/4 inches. The valve has a stainless steel spring, is auto-re-seating, and meets CSA 4.4 standards.

This temperature and pressure relief valve has a factory-set pressure at 150 psi with a maximum temperature of 210 Degrees F and 185,000 BtuH. Its thermostat length is 1 5/32 inches, shank length is 5 7/32 inches, and bronze body measures 1 17/32 x 5 7/32 inches. Its MNPT inlet and FNPT outlet each measure 3/4 inches. The valve has a stainless steel spring, is auto-re-seating, and meets CSA 4.4 standards.

This temperature and pressure relief valve has a factory-set pressure of 150 psi and a maximum temperature of 210 Degrees F with 500,000 BtuH. Its thermostat length is 4 3/4 inches, shank length is 6 7/8 inches, and the body measures 1 9/16 x 6 7/8 inches. The inlet and outlet is FNPT with a one-inch inlet and 3/4-inch outlet. The valve is auto re-seating and includes a stainless steel spring. It meets CSA 4.4 standards.

This temperature and pressure relief valve has a factory-set pressure of 150 psi and a maximum temperature of 210 Degrees F with 500,000 BtuH. Its thermostat length is 4 3/4 inches, shank length is 6 7/8 inches, and the body measures 1 9/16 x 6 7/8 inches. The inlet and outlet is FNPT with a one-inch inlet and 3/4-inch outlet. The valve is auto re-seating and includes a stainless steel spring. It meets CSA 4.4 standards.

This temperature and pressure relief valve has a 3/4-inch MNPT inlet and 3/4-inch FNPT outlet, with a factory-set 150 psi and is suitable up to 210 Degrees F. Its thermostat length is 1 9/16 inches, shank length is 1 3/16 inches, and its bronze body measures 1 3/32 x 2 5/8 inches. The spring is stainless steel and the valve is auto re-seating. It meets CSA 4.4 standards.

This temperature and pressure relief valve has a 3/4-inch MNPT inlet and 3/4-inch FNPT outlet, with a factory-set 150 psi and is suitable up to 210 Degrees F. Its thermostat length is 1 9/16 inches, shank length is 1 3/16 inches, and its bronze body measures 1 3/32 x 2 5/8 inches. The spring is stainless steel and the valve is auto re-seating. It meets CSA 4.4 standards.

This bronze, temperature and pressure relief valve has a 3 1/16-inch long thermostat, 1 3/16-inch shank length, and the body measures 1 5/32 x 3 inches. It has a factory-set pressure of 150 psi, with a maximum temperature of 210 Degrees F and 105,000 BtuH. The MNPT inlet and FNPT outlet each measure 3/4 inches, and the valve is auto-re-seating with a stainless steel spring. It is CSA 4.4 compliant.

This bronze, temperature and pressure relief valve has a 3 1/16-inch long thermostat, 1 3/16-inch shank length, and the body measures 1 5/32 x 3 inches. It has a factory-set pressure of 150 psi, with a maximum temperature of 210 Degrees F and 105,000 BtuH. The MNPT inlet and FNPT outlet each measure 3/4 inches, and the valve is auto-re-seating with a stainless steel spring. It is CSA 4.4 compliant.

This temperature and pressure relief valve has a maximum temperature of 210 Degrees F with 500,000 BtuH, and a factory-set pressure of 150 psi. The thermostat length is four inches, the shank length is 6 7/8 inches, and the bronze body measures 1 19/32 x 6 7/8 inches. It has a one-inch MNPT inlet and a 3/4-inch FNPT outlet. This valve is auto re-seating and has a stainless steel spring. It meets CSA 4.4 standards.

This temperature and pressure relief valve has a maximum temperature of 210 Degrees F with 500,000 BtuH, and a factory-set pressure of 150 psi. The thermostat length is four inches, the shank length is 6 7/8 inches, and the bronze body measures 1 19/32 x 6 7/8 inches. It has a one-inch MNPT inlet and a 3/4-inch FNPT outlet. This valve is auto re-seating and has a stainless steel spring. It meets CSA 4.4 standards.

This temperature and pressure relief valve has an MNPT inlet and FNPT outlet that are 3/4 inches each. Its bronze body measures 1 15/32 x 4 5/16 inches, and it has a 1 9/16-inch long thermostat and 2 5/8-inch long shank. The pressure is factory-set at 150 psi, with a maximum temperature of 210 Degrees F and 105,000 BtuH. The valve has a stainless steel spring and is auto-re-seating. It is CSA 4.4 and compliant.

This temperature and pressure relief valve has an MNPT inlet and FNPT outlet that are 3/4 inches each. Its bronze body measures 1 15/32 x 4 5/16 inches, and it has a 1 9/16-inch long thermostat and 2 5/8-inch long shank. The pressure is factory-set at 150 psi, with a maximum temperature of 210 Degrees F and 105,000 BtuH. The valve has a stainless steel spring and is auto-re-seating. It is CSA 4.4 and compliant.

This bronze, temperature and pressure relief valve has a 4 3/4-inch long thermostat, 6 7/8-inch long shank, and 1 1/2 x 6 7/8-inch body. The MNPT inlet and FNPT outlet each measure 3/4 inch. This auto re-seating valve has a stainless steel spring, a factory-set pressure of 150 psi, and a maximum temperature of 210 Degrees F with 205,000 BtuH. It is CSA 4.4 compliant.

This bronze, temperature and pressure relief valve has a 4 3/4-inch long thermostat, 6 7/8-inch long shank, and 1 1/2 x 6 7/8-inch body. The MNPT inlet and FNPT outlet each measure 3/4 inch. This auto re-seating valve has a stainless steel spring, a factory-set pressure of 150 psi, and a maximum temperature of 210 Degrees F with 205,000 BtuH. It is CSA 4.4 compliant.

This temperature and pressure relief valve has a factory-set pressure of 150 psi and a maximum temperature of 210 Degrees F with a 750,000 BtuH. It has a bronze, 1 3/4 x 5 7/8-inch body, a 4 3/4-inch long thermostat, and a shank length of 5 7/8 inches. The inlet and outlet are FNPT, with a one-inch inlet and 3/4-inch outlet. The valve is auto re-seating and has a stainless steel spring. It meets CSA 4.4 standards.

This temperature and pressure relief valve has a factory-set pressure of 150 psi and a maximum temperature of 210 Degrees F with a 750,000 BtuH. It has a bronze, 1 3/4 x 5 7/8-inch body, a 4 3/4-inch long thermostat, and a shank length of 5 7/8 inches. The inlet and outlet are FNPT, with a one-inch inlet and 3/4-inch outlet. The valve is auto re-seating and has a stainless steel spring. It meets CSA 4.4 standards.
