AMPROBE PROF DMM TRUE RMS W/COMPONENT LOGIC - Digital Multimeters - FET37XR-A

PROF DMM TRUE RMS W/COMPONENT LOGIC

AMPROBE

close x

images.360.info.textHead1 360° images.360.info.textHead2

Rotate: Use top-to-bottom, side-to-side by use of mouse arrow.
Zoom In: Double click on image.
Zoom Out/Reset: Put photo at full zoom & then double click.

Roll over image to zoom.

360°

PROF DMM TRUE RMS W/COMPONENT LOGIC

AMPROBE

Web Price : $560.63 / EACH

Compliance and Restrictions

None

Compare

Availability

Pick Up

Shipping

Item # FET37XR-A
Mfr. Model # 37XR-A
UNSPSC # 41113630
CATALOGUE PAGE # 152
Shipping Weight 1.7 lbs

Technical Specs

Item Digital Multimeter
Basic AC Voltage Accuracy +/- (1.2 % rdg + 10 dgts)
Data Hold Yes
Instrument Safety Rating CAT III 300 V, CAT II 600 V, CAT I 1,000 V
Maximum DC Voltage Measurement 1,000 V
Special Features 10 Amps AC/DC, Fully Safety Fused, Auto Power Off to Save Battery Life, Autoranging, Backlight, True-RMS with Component and Logic Test, Continuity Beeper, Display Update Rate: 2/sec, Nominal, Display: 4-3/4 Digit LCD, 10,000 Counts with 41-Segment Analog Bar Graph, Inductance to 40 H, Frequency to 40 MHz, Capacitance to 400 Îf, Logic to 20 MHz, Input Warning Tone When Test Leads are in Wrong Jack, Magne-Grip(TM) Holster with Magnetic Hanging Strap, Min/Max, Average, Relative, Peak and Data Hold, Operating Temperature: 0 Degrees C to 45 Degrees C at Less Than70% R.H, Power Battery: 9 V Neda 1604, JIS 006P, IEC 6F22, Separate Door for Easy Battery and Fuse Access
Calibration Certificate Included No
Multimeter Style Full Size
Capacitance Measurement Accuracy +/- (3.0 % rdg + 5 dgts)
Bluetooth Compatible No
Dustproof No
Removable Screen No
Waterproof No
Temperature Measurement Accuracy Not Applicable
Resistance Measurement Accuracy +/-2%
AC Voltage Measurement Resolution 1 V
Auto Ranging Yes
Batteries Included Yes
Battery Chemistry Alkaline
Battery Voltage 9V
Computer Interface Connection Type None
DC Current Measurement Resolution 1 uA
Depth 2.4 in
Display Type LCD
Frequency Measurement Resolution 100 Hz
Includes 9V Battery (Installed), Magne-Grip(TM) Holster with Magnetic Hanging Strap, Spare Fuse, Test Leads with Threaded Alligator Clips
Maximum Capacitance Measurement 400 uF
Maximum Operating Temperature 113 Degrees F
Maximum Sound Level Measurement 50 dB
Maximum Temperature Measurement 113 Degrees F
Minimum AC Voltage Measurement 1 V
Minimum DC Current Measurement 1 uA
Minimum Frequency Measurement 100 Hz
Minimum Resistance Measurement 1,000 ohm
Minimum Temperature Measurement 32 Degrees F
Overall Height 7.7 in
Peak Hold Yes
Standards US-CSA-C, UL, OSHA
True RMS Bandwidth 2 kHz

Audible Continuity Yes
Basic DC Voltage Accuracy +/-0.50% + 2 Digits
Basic DC Current Accuracy +/- (0.5 % rdg + 5 dgts)
Maximum AC Voltage Measurement 1,000 V
Instrument Counts 10,000
Maximum AC Current Measurement 10 A
Maximum DC Current Measurement 10 A
Basic AC Current Accuracy +/- (1.5 % rdg + 10 dgts)
Frequency Measurement Accuracy +/- (0.1 % rdg + 5 dgts)
Current Leakage Testing No
Intrinsically Safe No
Thermal Imaging No
Parameters Measured AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Frequency, Resistance
AC Response Calculation TRMS
AC Current Measurement Resolution 1 uA
Auto Power Off Yes
Bar Graph Included Yes
Battery Access Yes
Battery Size 9V
Capacitance Measurement Resolution 40 nF
Data Logging No
DC Voltage Measurement Resolution 1 V
Diode Test Yes
Duty Cycle Yes
Fuse Access Yes
Manufacturers Warranty Length 3 yr
Maximum Frequency Measurement 10 MHz
Maximum Resistance Measurement 40 megaohm
Maximum Storage Temperature 140 Degrees F
Minimum AC Current Measurement 1 uA
Minimum Capacitance Measurement 40 nF
Minimum DC Voltage Measurement 1 V
Minimum Operating Temperature 32 Degrees F
Minimum Storage Temperature -4 Degrees F
Minimum/Maximum Memory Yes
Overall Width 3.6 in
Resistance Measurement Resolution 1,000 ohm
Temperature Measurement Resolution 0 Degrees C
Weight 1 lb
